Patent Information
In accordance with the virtual marking provisions of various jurisdictions, including the virtual marking provisions of the America Invents Act, the following charts identify representative products that may be protected by various patents in the US & elsewhere. Certain products also may be covered by related international patents, or related pending applications.
-
Belden
-
GarrettCom
-
Hirschmann
-
Mohawk
-
PPC
-
Thinklogical
-
Tripwire
Belden Cable & Connectivity Patents
GarrettCom Patent Information
| Representative Marks/Products | Representative Product Image(s) | Representative Part No(s) | Representative US Patents |
|---|---|---|---|
| PES42: PoE Power-Source Edge Switch with 4 PoE Ethernet Ports | ![System.String[]](https://assets.belden.com/transform/695619a1-0aa1-4ffa-8124-8245af3ef204/PES42-PoE-Power-Source-Edge-Switch-4-Ports-Garrettcom-2020-10?io=transform:fill,width:275,height:200)
| PES42P-ff-48VDC PESD42H-ff-48VDC PESD42P-ff-48VDC | 8,902,760 | 9,019,838 |
| PS14: 4-port 10/100 Mb PoE Switch | ![System.String[]](https://assets.belden.com/transform/e4ae9882-b3d5-4db8-834f-769f58e367bc/PS14-4-port-10-100-Mb-PoE-Switch-Garrettcom-2020-10?io=transform:fill,width:275,height:200)
| PS14H-48VDC PS14P-48VDC | 8,902,760 | 9,019,838 |
| 6KL: 10-port Managed Edge Switches with optional 8 PoE ports | ![System.String[]](https://assets.belden.com/transform/efcbde52-ccd5-430b-a26a-bba0cb5b4cd0/GarrettCom-Magnum-6KL-Switches?io=transform:fill,width:275,height:200)
| 6KLP-48VDC P6KL4-RJ45 6KLP-48VDC PP6KL4-RJ45 | 8,902,760 | 9,019,838 |
| 6KQ 16-port Managed Edge Switches with optional 8 PoE ports | ![System.String[]](https://assets.belden.com/transform/01502b76-e21b-45c7-9cbb-1d749430aa7e/6KQE-10-port-Managed-Edge-Switches-with-optional-4-PoE-ports-Garrettcom-2020-10?io=transform:fill,width:275,height:200)
| 6KQP-48VDC P6KQ4-RJ45 | 8,902,760 | 9,019,838 |
| 6KQE 10-port Managed Edge Switches with optional 4 PoE ports |
| 6KQEP-48VDC | 8,902,760 | 9,019,838 |
| 6KM 10-port Managed Edge Switches with optional 8 PoE ports | ![System.String[]](https://assets.belden.com/transform/a69b5c9a-27a3-4e62-b557-0c27c8ebd772/GarrettCom-Magnum-6KM-Switches?io=transform:fill,width:275,height:200)
| 6KMP-48VDC P6KM4-4M12 | 8,902,760 | 9,019,838 |
| 6K16(V) 16-port Managed Edge Switches with optional 16 PoE ports | ![System.String[]](https://assets.belden.com/transform/afe06718-dbde-49e4-81d2-b64e78e340cc/GarrettCom-Magnum-6k16-Switches?io=transform:fill,width:275,height:200)
| 6K16(V)-48VDC P6KP7V-xxxx 6K16(V)-48VDC P6KP8V-xxxx 6K16(V)-48VDC P6KP6V-xxxx | 8,902,760 | 9,019,838 |
| 6K25(e) 26-port Managed Switch with optional 24 PoE ports | ![System.String[]](https://assets.belden.com/transform/1ff51224-87a5-4fe8-b3f7-4ec683f2a84d/GarrettCom-Magnum-6k25-Switches?io=transform:fill,width:275,height:200)
| 6K25(R)e-48VDC P6KPXV-xxxx 6K25(R)e-125VDC P6KPXV-xxxx 6K25(R)e-2AC P6KPXV-xxxx 6K25(R)e-2DC | 8,902,760 | 9,019,838 |
| 6K32 (T.F) 32-port Managed Switch with optional 32 PoE ports |
| 6K32(F/T)(R) -48VDC P6KPXV-xxxx 6K32(F/T)(R) -125VDC P6KPXV-xxxx 6K32(F/T)(R) P6KPXV-xxxx | 8,902,760 | 9,019,838 |
| 10KT 36-port Managed Switch with optional 32 PoE ports | ![System.String[]](https://assets.belden.com/transform/e1eb3ef4-dab1-4a22-b5db-87ff956a8ab5/10KT-36-port-Managed-Switch-with-optional-32-PoE-ports-Garrettcom-2020-10?io=transform:fill,width:275,height:200)
| 10KTP(R)-XXX 10K4P-RJ45 10KTP(R)-XXX 10K4PX-RJ45 10KTP(R)-XXX HSPM-L... | 8,902,760 | 9,019,838 |
| 10KG 24-port Managed Switch with optional 16 PoE ports | ![System.String[]](https://assets.belden.com/transform/fbcd4361-dcce-43ca-8e5b-370a629ab3f5/GarrettCom-Magnum-10k-Switches?io=transform:fill,width:275,height:200)
| 10KGP(R)-XXX 10K4PX-RJ45 10KGP(R)-XXX HSPM-L 10K4PX-RJ45 | 8,902,760 | 9,019,838 |
| 10XTS Router Terminal Server with 4 optional PoE ports | ![System.String[]](https://assets.belden.com/transform/96037e6b-583f-40f4-9e10-1b8aaad3f5fa/10XTS-Router-Terminal-Server-with-4-optional-PoE-ports-Garrettcom-2020-10?io=transform:fill,width:275,height:200)
| 10XTSP(R)-xxxx 10K4PX-RJ45 10XTSP(R)-xxxx HSPM-L 10K4PX-RJ45 | 8,902,760 | 9,019,838 |
PSE Devices
| Representative Marks/Products | Representative Product Image(s) | Representative Part Numbers | Representative US Patents* |
|---|---|---|---|
| MACH104 Ethernet Switch & Media Module with PoE | ![System.String[]](https://assets.belden.com/transform/5dde2236-d8c6-461e-b1e5-e6156b8779a2/Hirschmann-MACH-104-Switches?io=transform:fill,width:275,height:200)
| MACH104-20TX-F-4PoEP-x MACH104-16TX-PoEPx M1-8TP-RJ45 PoE | 8,902,760 9,019,838 |
| MACH 1000 Switches with PoE | ![System.String[]](https://assets.belden.com/transform/c5e19ca6-ee0b-493b-a330-91894949ccea/Hirschmann-MACH1000-Switches-PoE?io=transform:fill,width:275,height:200)
| MAR1032-CCTTTTxxxxxxxxxxxxxxxx MAR1032-4TTTTTxxxxxxxxxxxxxxxx MAR1032-4OTTTTxxxxxxxxxxxxxxxx | 8,902,760 9,019,838 |
| SPIDER Ethernet Switch with PoE | ![System.String[]](https://assets.belden.com/transform/33fbb79c-73b7-472e-ab53-524f948b8fcd/Hirschmann-SPIDER-Switches?io=transform:fill,width:275,height:200)
| SPIDER 1TX/1FX-MM PD EEC SPIDER 1TX/1FX-SM PD EEC SPIDER Giga 2TX PoE EEC | 8,902,760 9,019,838 |
| SPIDER II Ethernet Switch with PoE |
| SPIDER II 8TX PoE | 8,902,760 9,019,838 |
| OS24/32 Ethernet Switch with PoE | ![System.String[]](https://assets.belden.com/transform/4827dda0-75e1-4935-b356-8410335b42e7/Hirschmann-OS24-OS32-Ethernet-Switch-PoE?io=transform:fill,width:275,height:200)
| OS24-1012001MT5T5-TFFZ999HHSE2 OS24-081000T5T5TFFUHB OS32-081602T6T6TPEPHH OS32-081602T6T6TPE | 8,902,760 9,019,838 |
| MICE PoE Media Module | ![System.String[]](https://assets.belden.com/transform/56644f21-e37e-448f-90be-c489eeabeb21/Hirschmann-MICE-Media-Module-PoE?io=transform:fill,width:275,height:200)
| MM22-T1T1T1T1SZHH MM22-T1T1T1T1SYHH MSM42-T1T1T1T1SZ9HH9E99.9 | 8,902,760 9,019,838 |
| RS Ethernet Switch with PoE | ![System.String[]](https://assets.belden.com/transform/c0bcbe8c-d5b1-476d-bd59-88863c0fd23a/Hirschmann-RS-Ethernet-Switch-PoE?io=transform:fill,width:275,height:200)
| RS32-1602O6O6SPAEHFXX.X RS32-1602OOZZSPAEHFXX.X RS22-0800S2S2SPHEHFXX.X RS22-2400T1T1SPAEHFXX.X | 8,902,760 9,019,838 |
| OCTOPUS Ethernet Switch with PoE | ![System.String[]](https://assets.belden.com/transform/074c8ad6-8504-4bfc-9b34-088908ccde7b/Hirschmann-OCTOPUS-Ethernet-Switches?io=transform:fill,width:275,height:200)
| OCTOPUS 8M-8PoE | 8,902,760 9,019,838 |
| RSPE Ethernet Switch with PoE | ![System.String[]](https://assets.belden.com/transform/88a2f797-b806-430c-bc2e-c841717fec76/Hirschmann-RSP-RSPL-RSPE-Switches?io=transform:fill,width:275,height:200)
| RSPE37-24044O7T99-SPPV999HHHE2 RSPM22-4T14T1SZ9HHS999.9.99 RSPM22-4T14T1SV9HHS999.9.99 | 8,902,760 9,019,838 |
| GREYHOUND PoE Media Module | ![System.String[]](https://assets.belden.com/transform/88718323-c08f-4c36-8376-a207b12844db/Hirschmann-GREYHOUND-PoE-Media-Module?io=transform:fill,width:275,height:200)
| GMM42-TTTTTTTTSV9HHS999.9 GMM42-OOOOTTTTSV9HHS999.9 | 8,902,760 9,019,838 |
PD Devices
| Representative Marks/Products | Representative Product Image(s) | Representative Part Numbers | Representative US Patents* |
|---|---|---|---|
| SPIDER Ethernet Switch |
| SPIDER 5TX PD EEC SPIDER 1TX/1FX-MM PD EEC SPIDER 1TX/1FX-SM PD EEC | 8,155,012 8,942,107 |
| OpenBAT R (or) F Wireless Access Point | ![System.String[]](https://assets.belden.com/transform/f94c7948-b306-4d01-83b8-d5a3e34e9d84/Hirschmann-OpenBAT?io=transform:fill,width:275,height:200)
| BAT-RUSW99AWW99B07T1S999ZHXX.X BAT-RUSW99AWW99B07T1S999ZHXX.X BAT-RUSW99AP9F9AO7T1S999ZHXX.X BA | 8,155,012 8,942,107 |
| BAT450 Wireless Access Point | ![System.String[]](https://assets.belden.com/transform/2a61ee08-691a-461d-91e3-8d786869acb6/Hirschmann-BAT450-F?io=transform:fill,width:275,height:200)
| BAT450-FUSW99CW999AT699T9999HX BAT450-FUSW99AW999AT6T6T999ZHX BAT450-FUSW99AW999AT699T999ZHX | 8,155,012 8,942,107 |
Mohawk Patent Information
Visit the PPC Patents page for full details.
Visit the Thinklogical Patents page for full detail.
Visit the Tripwire Patents page for full detail.
